This Close " to cutting off heel shifter

[1olbull]

Nope. Don't know what they call it. Have seen another in pics. I like it too. I like to ride with just the front of the foot planted and the heel free. The shifter is in the way. Want to keep all the original part in case the next owner wants them or I have to revert back for a reason like yours.

I understand your issue. Because the Triumph shifter is NOT splined, it can not be adjusted downward out of the way of your heel, as I have done with my Kaw V2K. I found a splined shifter from a Thunderbird that worked for my R3R and eliminated all the linkage crap.
The distance from the engine spline to the shifter toe location does varry from the R3R to the Standard & Classic so, measuring your bike followed by a comprehensive search will be in order. Good fortune with your mod!



[R3Tex]

I understand your issue. Because the Triumph shifter is NOT splined, it can not be adjusted downward out of the way of your heel, as I have done with my Kaw V2K. I found a splined shifter from a Thunderbird that worked for my R3R and eliminated all the linkage crap.
The distance from the engine spline to the shifter toe location does varry from the R3R to the Standard & Classic so, measuring your bike followed by a comprehensive search will be in order. Good fortune with your mod!

Year model on the Tbird?



[1olbull]

Year model on the Tbird?

I went to the Tacoma Triumph Dealer (now defunct) and parused all the motors on the floor.
I didn't pay attention to the exact T-Bird model or year.
Tis a straight shaft and is 4¼ inch from center spline to center toe peg.
Parts fiche shows the same part for 2009 thru 2016 Thunderbird - T2082815 (assembly).
Has worked well for me the past two ride seasons.
BUT to be picky, I would go with an extra inch length if I could find one.
Here is a pix:


LOOK at what I just found!!! Tis what I bought for a shifter:

The listed part numbers are Bike Bandit numbers - not Triumph, which I believe is 2082811 (shaft only).
@R3Tex



[Ishrub]

your paint colors is like mine not to many painted like that. do u know the colors?
i was going to cut that heel off then i broke my leg and when i finally got back on the bike the only way i could shift was with the heel shifter.

Post#3 Paint codes

Rocket 111 (Classic) 2007
- Phantom Black Pearl PR IVC L5029 T3120300-PR / Tornado Red DUPONT CM BEC 2211 T3120300-CM or IVC L2804 T3120300-CM

'Tornado Red' is much a lighter and brighter red than 'Sunset Red'

Rocket 111 (Classic) 2007
- Phantom Black Pearl PR IVC L5029 T3120300-PR / Sunset Red CP DUPONT BEC1661T T3120300-CP

My 2006 Sprint ST 1050 is 'Sunset Red' too. Some call it generically a 'claret red wine ' color.

But yours does appear to be reversed primary color, unless the 'Tornado Red' versions all came that way.



Link Removed



[1olbull]

I like that "Racing Yellow"!



[WyldCFH]

I like that "Racing Yellow"!

Bah! No one likes yellow... especially as racing stripes on nice black Rockets



[WyldCFH]

Why thank you sir! Yes I am number 1



[Ishrub]

I went to the Tacoma Triumph Dealer (now defunct) and parused all the motors on the floor.
I didn't pay attention to the exact T-Bird model or year.
Tis a straight shaft and is 4¼ inch from center spline to center toe peg.
Parts fiche shows the same part for 2009 thru 2016 Thunderbird - T2082815 (assembly).
Has worked well for me the past two ride seasons.
BUT to be picky, I would go with an extra inch length if I could find one.
Here is a pix:


LOOK at what I just found!!! Tis what I bought for a shifter:

The listed part numbers are Bike Bandit numbers - not Triumph, which I believe is 2082811 (shaft only).
@R3Tex

From *NEW OLD STOCK* TRIUMPH THUNDERBIRD 1600 / 1700 GEAR LEVER PEDAL T2082811 NOS | eBay

To Fit Make:

Triumph Manufacturer Part Number: T2082811
To Fit Model: THUNDERBIRD 1600 / 1700 Other Part Number: T2081636 T2026182 T2082815

#T2082815: Gear Pedal, Spares Kit

Gear Pedal, Spares Kit
Part Number: T2082815
> 436181 ; N/A to Special Edition

Gear Selectors & Pedal
#3
> 436181 ; N/A to Special Edition. Required: 1

1
Gearchange Pin
Required: 1 T2081746 $6.64

2
Rubber, Gear Pedal
Required: 1 T2026182 $29.71

3
Gear Pedal, Forged
436182 > ; N/A to Special Edition. Required: 1 T2082811 $14.50

3
Gear Pedal, Forged. 436182 > ; N/A to Special Edition
436182 > ; N/A to Special Edition. Required: 1 T2082811 $14.50

3
Gear Pedal, Spares Kit. > 436181 ; N/A to Special Edition
> 436181 ; N/A to Special Edition. Required: 1 T2082815 $32.18

4
Screw, Cap/Hd, M6 x 20, Slv
Required: 2 T3050334 $0.97



[1K9]

Took the hacksaw and grinder to it. Can still heel shift OK but can use the whole platform to change foot positions. If the heel peg is ever needed will drill the shifter and bolt a peg on. Now, what do I do with the non fitting shifter pedal collection?



[1K9]

Sorry, could not resist it It's Rocket related Okaaay, no mas



The butcher job


Look Tex on his new wheels taking flight !
