'06 Classic Heel/Toe Shifter to just Toe Shifter

[barbagris]

Hey barbagris, If you get a chance and can find a pic of your set-up then I'd appreciate it, thanks

I have since made a MUCH better linkage rod with proper rose-joints

And here is a comparison of Tarrozi - heel-toe and standard levers.

Note the heel-toe and Tarozzi share the same pivot diameter (luck) - the simple lever is different.



[barbagris]

I eliminated all the unnecessary linkage and mounted a Bonneville shift lever direct to the splined shaft.

Are those Classic boards? - or the higher footboards?



[barbagris]

Would you or anyone, know if this type of heel toe shifters will fit my 2005 R3, I for one like this type of shifter; Thanks big guy and "Be Safe!

Getting the Triumph one to fit would be a challenge - The dimensions are all different.



[cdlamph]

I have since made a MUCH better linkage rod with proper rose-joints

And here is a comparison of Tarrozi - heel-toe and standard levers.

Note the heel-toe and Tarozzi share the same pivot diameter (luck) - the simple lever is different.

Nice, that looks like something I might be able to do if I can't replace the floorboards and all. Thanks for the pics.



[1olbull]

Are those Classic boards? - or the higher footboards?

They are the Standard boards, which are higher and provide more ground clearance.
I do have a new heel/toe shifter that came with it. Supposedly it is very rare.



[barbagris]

They are the Standard boards, which are higher and provide more ground clearance.
I do have a new heel/toe shifter that came with it. Supposedly it is very rare.

Thought it best to ask - point out that with Classic boards the "bul" lever conversion lever will sit higher above the board.



[cdlamph]

barbagris, Do you remember what size rose joints you used? The only info from Google searching ended up from a HD forum.



[barbagris]

Just bog standard M6 rose joints - I walked into a bearing supply place and said - "Rose Joints - 6mm" - In the US I believe they all called HEIM JOINTS

Mine are similar but the threaded part is "female" M6 ISO-C thread - Diameter "C" 6mm



[cdlamph]

Just bog standard M6 rose joints - I walked into a bearing supply place and said - "Rose Joints - 6mm" - In the US I believe they all called HEIM JOINTS

Mine are similar but the threaded part is "female" M6 ISO-C thread - Diameter "C" 6mm

Very Cool. I can find the Heim Joints, thanks for that. The problem I have now is locating a connecting rod with LH/RH ends, might have to make one myself.



[barbagris]

Very Cool. I can find the Heim Joints, thanks for that. The problem I have now is locating a connecting rod with LH/RH ends, might have to make one myself.

I didn't bother. I got two normal thread joints and made a rod with some bar.
A 6mm has a 1.0 mm pitch - Half a turn is only 0.5mm - Ok you need to whip it off to adjust - but it's not a game changer.
