Transmission went south

Ishrub

Retired and loving it!
Joined
Feb 18, 2016
Messages
7,265
Location
Duffy, Canberra, ACT, AUSTRALIA
Ride
R3 Roadster,Sprint ST 1050 ABS, BMW R100RS sidecar
Treasure of the Sierra Madre, I believe.
Your much better at remembering this sort of sh!t than I am. I didn't remember that. ;) 😁
Gold Hat: Badges? We ain't got no badges. We don't need no badges. I don't have to show you any stinking badges.


FE_rex

Bob Wills is still the King
Joined
Jul 17, 2017
Messages
904
Location
TEXAS
Ride
2006 Rocket III

sonny

Living Legend
Joined
Sep 24, 2015
Messages
8,094
Location
Henryetta Oklahoma
Ride
rocket three x
At 68,000 and with the bike about to be torn apart I do believe three piston ring sets might be in order. Some of the stuff ordered from Hermy's came in yesterday but not much. Mostly speciality tools. Just a footnote R-III-R Turbo is really a good and helpful individual. I believe doing business with him is going to be a pleasure. The guy goes out of his way when it comes to customer service. Right up there with Paul and Lush.


Ishrub

Retired and loving it!
Joined
Feb 18, 2016
Messages
7,265
Location
Duffy, Canberra, ACT, AUSTRALIA
Ride
R3 Roadster,Sprint ST 1050 ABS, BMW R100RS sidecar
You will regret not spending a few hundred more for a set mild 10.5:1 forged pistons. Nothing wild but 3-400 in a 15,000 build is piece of mind and should match your Lush street cams as I believe Neville may sell something similar with his street cams.

I have a set I'm saving for a build.

JE Pistons, Powersports 317209 Pistons ........Great photos in link!

Bore (in)4.
Bore (mm)101.6
Top Compression Ring Thickness0.0480
Second Compression Ring Thickness0.0600
Oil Ring Thickness0.119
Forging TypeFSR
Volume (cc)3.30
SeriesPowersports
Piston Head TypeDome
Pin Diameter (IN)0.866
Compression Height1.161
Wrist Pin Style - floating or press fitFloating
Wall TypeCHAMFERED
Wall Thickness (IN)0.150
Ringset Part NumberJG3101-4000-7
Ring BrandProSeal
Ringset IncludedYes
Retainer Thickness0.063
Retainer Lock StyleWire Lock
Retainer Lock Part Number866-063-MW
Retainer Diameter (IN)0.866
Replacement Single Piston317209S
Piston Pin Inside Diameter0.566
Piston Pin Material5115 LOW CARBON STEEL, CASE HARDENED
Piston Material2618
Piston Pin Length (IN)2.250
Piston Avg Wt361
Pin OffsetNo
Pin BrandJE Pistons
Pin Part Number866-2250-15-51C
Pin IncludedYes
Pin Diameter (mm)22.00
Oil Rail Support IncludedNo
Deck Clearance0.000
BrandJE Pistons


They include all your rebuild bits.
Condition:NewBrand: JE Pistons
Oversize:Standard
Manufacturer Part Number: 317209
Compression Ratio: 10.5:1
End Displacement: 2249cc
Piston Weight: 361 grams
Bore Size: 101.6mm
Skirt Style: FSR

FREE DOMESTIC 1-3 DAY SHIPPING!$30 FEDEX 1-4 DAY INTERNATIONAL SHIPPING!

Sold as as engine set of 3 pistons, 3 sets of piston rings, 3 wrist pins, and 3 sets of pin lock rings.
  • Machined from 2618 T6 high tensile forged aluminum
  • Dome/Dish features smooth flowing radii and require no deburring or preparation
  • JE designs are specifically engineered for extreme applications including professional competition
  • Pins, pin fitment, lock and rings included

Triumph Models
  • Triumph Rocket III 2004 - 2009
  • Triumph Rocket III Classic 2006 - 2009
  • Triumph Rocket III Classic Tourer 2007 - 2011
  • Triumph Rocket III Classic Tourer 2-Tone 2008 - 2009
  • Triumph Rocket III Roadster 2010 - 2013
  • Triumph Rocket III Special Edition 2006
  • Triumph Rocket III Touring 2008 - 2013
  • Triumph Rocket III Touring 2-Tone 2011
  • Triumph Rocket III Touring ABS 2012
