Second Gear Slipping

Discussion in 'Common Issues' started by phar2slo, Jun 11, 2018.

Tags:
  1. phar2slo

    phar2sloTurbocharged

    Country:
    New Zealand
    Messages:
    727
    Featured Threads:
    7
    Likes Received:
    875
    Trophy Points:
    103
    Location:
    Christchurch
    Ride:
    2006 classic
    Hi all

    I'm having trouble with second gear 2006 model.

    It's feels as if when I'm giving it a bit of throttle the gear disengages then a loud clunk and away it goes.

    Been doing it for a while now but yesterday when it clunked back into place it was the loudest and I nearly filled me pants.

    So the main thing I need know is do I go down the road of buying the replacement up date kit cost of the complete kit in Kiwi dollars wait for it
    $2500.00.

    + a week's labour to replace the bits and bobs.

    Or can I get away with just getting the gears under cut and will this work.

    Have text message @sleeves and said get on the forum and get some advice from those that have already been there done that before.

    Also feels as if the clutch might be slipping too.

    Cheers

    Chris.

    BigNorm likes this.
  2. Pedro

    PedroTurbocharged

    Country:
    Australia
    Messages:
    503
    Featured Threads:
    3
    Likes Received:
    232
    Trophy Points:
    43
    Location:
    Rockingham , Western Australia
    Ride:
    05 TTS , Lush Rocket standard
    Strip it down and just buy what you need , be a lot less

    BigNorm, ozrider and phar2slo like this.
  3. mr hunt

    mr huntLiving Legend

    Country:
    Australia
    Messages:
    2,202
    Featured Threads:
    15
    Likes Received:
    2,833
    Trophy Points:
    823
    Location:
    Perth, WA
    Ride:
    2013 Roadster
    All the necessary components for a full rebuild will only set you back around 4k in Oz ...I'd do as Pedro has suggested...crack it open and replace what's worn/broken

    phar2slo likes this.
  4. cootertwo

    cootertwoNitrous

    Country:
    United States
    Messages:
    1,091
    Featured Threads:
    19
    Media:
    4
    Likes Received:
    1,624
    Trophy Points:
    223
    Location:
    Labelle Florida USA
    Ride:
    2013, & 2 05's R3R, 2006, 2004 Harley's, 2004 Kaw
    Just the update kit, alone, probably won't fix your problem.

    phar2slo likes this.
  5. Claviger

    ClavigerHP Junkie extraordinaire

    Messages:
    4,548
    Featured Threads:
    100
    Media:
    29
    Likes Received:
    5,196
    Trophy Points:
    823
    Location:
    Olympia Washington
    Ride:
    '14 R3R, '02 Daytona 955i
    Welcome to the “rounded dog” club. You’ll need to replace one or both in/out gears for second, but almost certainly the input will need replacing.

    The parts count isn’t all that bad but the labor if you have it done is considerable. It will ultimately be dictated by what other parts you replace but just gaskets and bolts is around $200 US when splitting cases.

  6. 1K9

    1K9Big Cruisers 4 Me

    Country:
    United States
    Messages:
    1,542
    Featured Threads:
    1
    Media:
    16
    Likes Received:
    1,264
    Trophy Points:
    323
    Location:
    Clear Lake / Houston, Texas
    Ride:
    2007 Rocket III
    The gears might be OK. Take the front off. Remove the clutch basket and service it. Change the detent spring. Remove the oil pan to see if the strainers saved bits of the gear. If they are clean perhaps when you reassemble it the bike will shift fine.

    Bedifferent and phar2slo like this.
  7. warp9.9

    warp9.9Pocałuj mnie w dupę

    Messages:
    7,425
    Featured Threads:
    9
    Media:
    14
    Likes Received:
    7,731
    Trophy Points:
    823
    Location:
    Forest City Illinois
    Ride:
    07 Rocket
    I agree with Pedro replace whats needed 2nd/3rd drive dog ring. Plus second gear along with the splined bushings between 2nd and 3rd gear output. If it would be me I woulds consider the billet 4th gear even if you do not get the trans gears undercutt and larger cir-clips done.

    Tripps, phar2slo and Nat67 like this.
  8. barbagris

    barbagrisMad Scientist

    Messages:
    7,337
    Featured Threads:
    48
    Media:
    83
    Likes Received:
    6,737
    Trophy Points:
    823
    Location:
    On the verge of insanity : Madrid - Spain
    Ride:
    2009 R3-Standard - 1979 Guzzi V1000G5
    [​IMG]

  9. Paul Bryant

    Paul BryantTop Fuel

    Country:
    New Zealand
    Messages:
    1,918
    Featured Threads:
    28
    Likes Received:
    3,891
    Trophy Points:
    323
    Location:
    Hamilton. New Zealand
    Ride:
    2006 Rocket
    Chris, when/if you strip the Engine I have the Alternator Rotor puller that you will require to get it apart, we'll be in touch.

  10. sleeves

    sleevesTurbocharged

    Country:
    New Zealand
    Messages:
    894
    Featured Threads:
    6
    Media:
    6
    Likes Received:
    960
    Trophy Points:
    203
    Location:
    Backblocks, Waikato, New Zealand
    Ride:
    05 R3 Std

    Yep what we discussed on the phone but needs to be confirmed.

    phar2slo and Paul Bryant like this.
